Lutz

Air Drum Pumps, Stainless Steel, 26 GPM

Model: DB829

  • Air Drum Pumps, Stainless Steel, 26 GPM Industrial Sales

Colour, sizing or style depicted in some photos may not be exactly as described.
Please check your product description carefully before placing your order.

$3,859.00 / Each

0 In Stock - Montreal Warehouse

Request Approx. Ship Date

Shipping times are based on information available at the time of order and are subject to change.

Max. Flow Rate

26 GPM

Material

Stainless Steel

Bearings

Carbon

Max. Ft. Of Head

42.5

Gravity

1.6

Specific Viscosity Cps

500

Wt. Lbs.

15

Motor Type

E.

  • MIXING DRUM PUMPS
  • Examples of Liquids: Alcohols, acetone, acetonitrile, acetates, ether, diethanolamine, freon frigen, methylene chloride, dimethyl phthalate, dioxane, diethylamine, pyridine, etc. ; MIXING DRUM PUMPS: Mixing pump tube is to be used where it is necessary to mix and pump in a single operation. Ideal for use in containers or in drums with a 2" bunghole. Drive shaft of pump tube is sealed by a single-acting mechanical seal and two shaft seals. Pump tube must not be allowed to run dry. Comes with 39" pump tube and stainless steel drive shaft. NOTE: Only DB837 and DB829 can be used for flammable liquids and include static kit. ; ; E. Compressed air motor: 300 W, 2/5 HP operating pressure is 87 PSI ; Note: Models DB838, DB816, DB821, DB822, DB829 and DB830 come with Hastelloy C drive shaft. ; Pumps that have a stainless steel construction come with a wall hanger, 10 ft. bonding wire and 26' grounding wires. ; Pumps that have a polypropylene construction come with a barrel adaptor, a wall hanger, 8' PVC hose and hose c-clamps (except DB827) .
